AIRCRAFT

Takeoff WeightDimensionsDiagonal Distance (propellers excluded)Max Ascent SpeedMax Descent SpeedMax SpeedMax Service Ceiling Above Sea LevelMax Flight TimeMax Hovering TimeOperating Temperature RangeSatellite Positioning SystemsHover Accuracy RangeTransmitter Power (EIRP)Operating Frequency

300 g

143×143×55 mm

170 mm

9.8 ft/s (3 m/s) in Sport Mode without wind

9.8 ft/s (3 m/s) in Auto Landing Mode

31 mph (50 kph) in Sport Mode without wind

13,123 feet (4,000 m)

16 minutes (no wind at a consistent 12.4 mph (20 kph))

15 minutes (no wind)

32° to 104° F (0° to 40° C)

GPS/GLONASS

Vertical:  +/- 0.1 m (when Vision Positioning is active) or +/-0.5 m Horizontal:  +/- 0.3 m (when Vision Positioning is active) or +/-1.5 m

2.4 GHz FCC: 25 dBm; CE: 18 dBm; SRRC: 18 dBm; MIC:18 dBm 5.8 GHz FCC: 27 dBm; CE: 14 dBm; SRRC: 27 dBm; MIC: -

2.400 - 2.483 GHz; 5.725 - 5.825 GHz

3D SENSING SYSTEM

Obstacle Sensing RangeOperating Environment

1-16 ft (0.2 - 5 m)

Detects diffuse reflective surfaces (>20%) larger than 20x20 cm (walls, trees, people, etc.)

CAMERA

SensorLensISO RangeElectronic Shutter SpeedImage SizeStill Photography ModesVideo ResolutionMax Video BitrateSupported File SystemsPhoto FormatVideo Format

1/2.3" CMOS  Effective pixels: 12 MP

FOV 81.9° 25 mm (35 mm format equivalent) f/2.6 (shooting range: 2 m to ∞)

Video: 100-3200  Photo: 100-1600

2-1/8000 s

3968×2976 1440×1080 with ShallowFocus 2300×1280 with Pano (horizontal)  960×1280 with Pano (vertical)

Single Shot  Burst Shooting: 3 frames  Auto Exposure Bracketing (AEB): 3 bracketed frames at 0.7 EV bias Interval: 2/3/5/7/10/15/20/30/60 s

FHD: 1920×1080 30p

24 Mbps

FAT32

JPEG

MP4 (MPEG-4 AVC/H.264)

REMOTE CONTROLLER

Operating FrequencyMax Transmission DistanceOperating Temperature RangeBatteryTransmitter Power (EIRP)Operating Current/VoltageSupported Mobile Device Size

2.412-2.462 GHz; 5.745-5.825 GHz

2.412 - 2.462 GHz (unobstructed, free of interference) FCC: 1.2 mi (2 km); CE: 0.3 mi (500 m) SRRC: 0.3 mi (500 m); MIC: 0.3 mi (500 m) 5.745 - 5.825 GHz (unobstructed, free of interference)  FCC: 1.2 mi (2 km); CE: 0.18 mi (300 m) SRRC: 0.7 mi (1.2 km); MIC: -

32° to 104° F (0° to 40° C)

2970 mAh

2.4 GHz  FCC: ≤26 dBm; CE: ≤18 dBm; SRCC: ≤18 dBm; MIC: ≤18 dBm 5.8 GHz  FCC: ≤28 dBm; CE: ≤14 dBm; SRCC: ≤26 dBm; MIC: -

950 mAh @3.7 V

Thickness range: 6.5-8.5 mm  Max length: 160 mm

INTELLIGENT FLIGHT BATTERY

CapacityVoltageMax Charging VoltageBattery TypeEnergyNet WeightCharging Temperature Range

1480 mAh

11.4 V

13.05 V

LiPo 3S

16.87 Wh

Approx. 0.2 lbs (95 g)

41° to 104° F (5° to 40° C)
